Relay 6 Person Hot Tub

$ $ $ $ $

The Hot Spring Hot Spot Relay 6 Person Hot Tub is a value-priced spa that seats six and includes a relaxing lounge seat. The comfortable Relay 6 Person Hot Tub is now ready for the new FreshWater Salt System that keeps your water clean for up to a year. With seating for 6, cushioned headrests and 40 targeted jets, there’s plenty of room for you, friends and family to relax. This value-packed spa is FiberCor® insulated and comes with a NoFault® heater. It also comes with dimmable multi-color LED lights for added ambiance.

The Relay Jet System offers an incredible 40 jets that relieve-tension in targeted areas including your back, neck, shoulders and calves. Directional Hydromassage Jets customize your massage — these unique jets rotate to give you soothing comfort exactly where you need it. Hot Spot Spas are designed to become a part of your everyday life. These spas offer jets that help you feel your best, in a package that fits your budget and your lifestyle.

Cabinet Colors: Almond, Havana, Storm
Shell Colors: Alpine White, Pearl, Pebble, Tuscan Sun
WeatherPro Cover Colors: Black, Chestnut, Gray

Almond Cabinet with Alpine White Shell

Almond Cabinet with Pearl Shell

Almond Cabinet with Pebble Shell

Almond Cabinet with Tuscan Sun Shell

Havana Cabinet with Alpine White Shell

Havana Cabinet with Pearl Shell

Havana Cabinet with Pebble Shelll

Havana Cabinet with Tuscan Sun Shell

Storm Cabinet with Alpine White Shell

Storm Cabinet with Pearl Shell

Storm Cabinet with Pebble Shell

Storm Cabinet with Tuscan Sun Shell

Hot Spot WeatherPro Cover Colors

FreshWater Salt System Ready

The FreshWater Salt System by Hot Spring Spas can keep your water sanitized, clean and clear for up to 1 year.

Jet System

Hot Spot Spas provide a carefully designed system of jets to soothe and target muscle groups from your neck to your toes.

Accent Lighting

Multi-colored LED lights accentuate your spa, inside and out. You control the mood!

Design

Designed to delight the senses, each spa features eye-catching finishes, dramatic LED lighting, sleek metallic corners, and distinctive design details.

Product Specs:

Download Product Specs PDF

Seating Capacity:

6 Adults

Dimensions:

7’ x 7′ x 36”H

Water Capacity:

340 gallons

Weight:

830 lbs. dry
4,715 lbs. filled (water + 6 adults)

Jet Count:

Hot Tub Jets:

3 XL Directional Hydromassage jets
2 XL Rotary Hyrdromassage jets
3 Directional Hydromassage jets
2 Rotary Hydromassage jets
30 Directional Precision® jets

Lighting System:

Interior – 10 multi-color LED points of light, dimmable
Exterior – 4 multi-color LED points of light, dimmable

Waterfall:

Included

Control System:

IQ 2020® with LCD control panel

Smart Spa Technology (optional):

Hot Spring Spas App powered by the Connected Spa Kit (sold separately)

Heater:

No-Fault®, 4000w/230v

Jet Pump 1:

Wavemaster® 6200 Two-speed
1.5 HP, continuous duty
3.2 HP, breakdown torque

Jet Pump 2:

Wavemaster® 6000 One-speed
1.5 HP, continuous duty
3.2 HP, breakdown torque

Insulation:

FiberCor® Insulation
CEC Certified

Electrical:

230v/50amp* Includes G.F.C.I protected subpanel
*Requires a dedicated circuit

Circulation Pump:

SilentFlo 5000® for quiet continuous filtration

Water Care System:

Freshwater Salt System Ready

Ozone System (Optional):

FreshWater III Ozone

Effective Filtration Area:

65 sq. ft. top loading filter

Cover:

– WeatherPro Cover
– Smartop Cover
– Covana Cover

Cover Colors:

– Black – Pairs with Havana
– Chestnut – Pairs with Almond
– Gray – Pairs with Storm

Entertainment System (Optional):

Wireless Sound System

Cover Lifters (Optional):

– Smartop Cover
– Covana Cover
– Lift ‘N Glide
– CoverCradle
– CoverCradle II
– UpRite

Steps (Optional):

– Hot Spot Collection Step
– Polymer

Bottom Seal:

Polyethelyne Sealed Bottom

Warranty:

5 Year No-Leak Shell
2 Year Shell Surface
2 Year No-Leak Plumbing
2 Year No-Fault Heater
2 Year Component
2 Year Simulated Wood Cabinet
2 Year Interior Light
1 Year Exterior Light
1 Year Wireless Audio
